Rental (7) Ahem Future Series Hobby Model 1400/20 Hydraulic Cylinders Series Assembly 1-7 all files .dxf

Description

Windows compatible only.

Single Assembly on a USB drive.

Assembly 7 Hobby Model 1400/20

• Each subscription is for not more than one Dugong Scraper assembly part and or not more than parts for one spare assembly Scraper part.
• Files: 7
• File name has material thickness in it
• { cutting time is estimated using 5mm per second for 6mm}
• { cutting time is estimated using 10mm per second for 3mm}
• Cutting time: 10 minutes
• Average file cut time 1 to 3 minutes
• Files cannot be edited but can have the power and speed changed.
• Photos can be used to assembly.
• Dowel: Two 16 millimetre thick pieces,  75 millimetre long. Drill hole up the centre of each to fit 8 millimetre dowel.
• Two pieces 8 millimetre thick and 75 millimetres long.
• Dowel: One 16 millimetre thick and 65 millimetres long. Drill hole up the centre to fit 8 millimetre dowel.
• Dowel: Six pieces 4 millimetre thick and 24 millimetres long. ( cylinder pins at each end )
• Material: MDF, Metal, Glass, Plastic, Acrylic, Wood
• Colour: To your own design
• 4300 millimetres total cut file length.
• 180 minutes rental of file.

Drawings have been nested to ensure a left and right hand method for metal and the small natural curving from cutting metal, assists overall fabrication alignment.

·       Photos can be used to assembly.

Rental Agreement – Engineering Drawings & Leaflets

This Rental Agreement applies to all Dugong Scrapers engineering drawings, documents, and leaflets made available under free listing access and after purchase.

Full Assembly Listings

Each full assembly rental includes 15 days of access from the time you activate. Opening the individual assembly files for the first time activates the countdown timer to expiry. During this rental period, the files may be viewed and used in accordance with the licence terms provided. Access to an assembly file set will automatically expire after 15 days. Individual parts contained within the assembly may have different rental timer periods, and access to those files will end once their individual timers expire.
