Rental (5) Ahem Future Series 900 Front Lift Series Assembly 1-10 all files .dxf

Description

Windows compatible only. Refer to assemblies for part numbers.

Single Assembly on a USB drive.

900 Assembly 5 front lift 900 series

951 Part 123 Cross beam plates 10mm 900s
Rental 210 minutes / 5100 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 250 x 420 millimetres.

952 Part 133 Lift boom front cap 10mm 900s
Rental 120 minutes / 2100 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 340 x 260 millimetres.

953 Part 134 Lifting boom 10mm 900s
Rental 150 minutes / 3600 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 940 x 440 millimetres.

954 Part 134A Lifting boom 10mm 900s
Rental 150 minutes / 3600 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 940 x 440 millimetres.

955 Part 134B Lifting boom name 10mm 900s
Rental 240 minutes / 6400 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 440 x 190 millimetres.

956 Part 141 Ram lift spacers 10mm 900s
Rental 120 minutes / 2600 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 360 x 240 millimetres.

957 Part 150 Roller plate 10mm 900s
Rental 180 minutes / 4600 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 1020 x 320 millimetres.

958 Part A 124 Double ram pack and ram hinges 10mm 900s
Rental 330 minutes / 9400 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 440 x 350 millimetres.

959 Part B 124 Double ram pack and ram hinges 10mm 900s
Rental 330 minutes / 9100 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 430 x 470 millimetres.

9510 Part C 124 Double ram pack and ram hinges 10mm 900s
Rental 360 minutes / 10,950 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 510 x 460 millimetres.

Drawings have been nested to ensure a left and right hand method for metal and the small natural curving from cutting metal, assists overall fabrication alignment.

·       Photos can be used to assembly.
