Rental (6) Ahem Future Series 900 Front Pull Series Assembly 1-10 all files .dxf

Description

Windows compatible only. Refer to assemblies for part numbers.

Single Assembly on a USB drive.

900 Assembly 6 front pull 900 series

961 Part 106 156 Backing plate draw bar tongue 10mm 900s
Rental 180 minutes / 4300 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 370 x 460 millimetres.

962 Part 106A hydraulic ass 10mm 900s
Rental 120 minutes / 2800 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 390 x 460 millimetres.

963 Part 125 Draw bar gusset 10mm 900s
Rental 90 minutes / 1950 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 760 x 280 millimetres.

964 Part 125A Draw bar gusset 10mm 900s
Rental 90 minutes / 1950 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 760 x 280 millimetres.

965 Part 128 Front draw bar 20mm 900s
Rental 150 minutes / 3300 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 1010 x 370 millimetres.

966 Part 128A Front draw bar 20mm 900s
Rental 150 minutes / 3300 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 1010 x 370 millimetres.

967 Part 135 163 Wear plates 20mm 900s
Rental 180 minutes / 4300 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 290 x 530 millimetres.

968 Part 137 Pull side arm 20mm 900s
Rental 180 minutes / 4800 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 1020 x 290 millimetres.

969 Part A 136 Pull side arm brace 10mm 900s
Rental 210 minutes / 5300 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 970 x 280 millimetres.

9610 Part B 136 Pull side arm brace 10mm 900s
Rental 210 minutes / 5300 millimetres drawing line length / steel 350 grade plate 10 millimetres thickness / box of 960 x 280 millimetres.

Drawings have been nested to ensure a left and right hand method for metal and the small natural curving from cutting metal, assists overall fabrication alignment.
